Power Output
Max Charging Power & Current | Single Gun 32A (1Φ) - 7.4kW 16A (3Φ) - 11kW 32A (3Φ) - 22kW | Dual Gun (Optional) 32A (1Φ) - 7.4kW 16A (3Φ) - 11kW 32A (3Φ) - 22kW |
AC Output Voltage | 184 - 276 Vac (1Φ L-N), 347 - 480 Vac (3Φ L-L) | |
Output Cable / Gun Type | 5m IEC 62196 Type 2 cable for each gun | |
Mode of Charging | Mode - 3 | |
Power Input
Input Voltage Range | 184 - 276 Vac (1Φ L-N), 347 - 480 Vac (3Φ L-L) | |
AC Wiring | 1Φ - L1/ N/ PE or 3Φ - L1/ L2/ L3/ N/ PE | |
Input Frequency (nominal) | 50 / 60 Hz | |
Input Frequency Range | 45 - 65 Hz | |
Standby Power @ Nom. Voltage | < 30 VA (single gun) |
Safety
Di-Electric Strength Test | 3,000 Vac (Common Mode) or 3,000 Vac (Differential) | |
Insulated Test Between Isolated Terminals | R >1M Ω | |
Over Voltage Category | III | |
Residual Current
| 30mA AC | 6 mA DC | |
Other Safety Features | Over Current, Under Voltage/Over Voltage, Over Temperature, Power Surge Protection, Earth Monitoring |
User Interface & Configuration
Display | LCD Display(Optional) | |
Support Language | English | |
User Authentication | RFID, SCharge Mobile App (for both Online charger & Offline charger via BLE), Free Vending, & 3rd Party OCPP | |
Connectivity Options | WiFi, BLE, Ethernet (RJ45), & 4G/LTE (Optional) | |
Visual Indication | LED | |
Other Communication | OCPP v 1.6 J (JSON) | |
Energy Metering | Class 1.0, UPF | |
Setup, Control, & Monitoring | SCharge Mobile app & SCharge CMS (optional) |
Load Management
Manual Load Limiting (Max) | 1A steps via App |
Mechanical
Ingress Protection | IP54 |
Impact Resistance | IK10 |
Dimension (H*W*D) | 41 X 27 X 17 (cm) |
Weight | 6.5 Kg (Single Gun) & 9.5kg (Dual Gun) |
Charging Cable Length | 5m |
Material | PC/PC-ASA |
Cable Storage | Cable & Gun Holder |
Mounting | Pedestal Stand or Wall |
Cooling | Natural Air |
Environmental
Operating Temperature | -10°C to 55°C (full power) |
Storage Temperature | -20°C to 60°C |
Altitude | 2,000 meters |
Humidity (Non-Condensing) | 5 % to 95 % |
Standards & Certification
Safety | IS 17017 (Part 1) - 2018 (For accuracy, Environment, & IP) |
